DNS for Developers: A, CNAME, MX, and TXT Records with dig

What you'll build

You'll configure the four DNS records every developer touches — A, CNAME, MX, and TXT — for a domain you own, then prove each one resolves correctly with dig and confirm worldwide propagation with online lookup tools.

Prerequisites

• A registered domain and access to its DNS management panel. Any provider works (Cloudflare, Route 53, Namecheap) — the record values are identical everywhere; only the dashboard differs.
• dig, part of ISC's BIND utilities. It's preinstalled on macOS and most Linux distros; on Debian/Ubuntu run sudo apt install bind9-dnsutils. On Windows, use WSL. Verified against DiG 9.10.6 (macOS) and the BIND 9.20 docs.
• A server IP to point at. I'll use 203.0.113.10 (a reserved documentation IP) and example.com as the domain — substitute your own values in every command.

1. Point your domain at a server with an A record

An A record maps a name to an IPv4 address. In your provider's DNS panel, add:

@ means the domain apex (example.com itself). TTL is how long resolvers may cache the answer, in seconds — use 300 while you're setting things up so mistakes expire in five minutes, and raise it to 3600+ once the record is stable.

2. Alias www with a CNAME record

A CNAME says "this name is an alias for that name" — resolvers restart the lookup at the target, so www automatically follows wherever the apex points:

Two rules bite people here: a name with a CNAME can hold no other records, and the spec forbids a CNAME at the apex — that's why providers reject @ here or offer flattened ALIAS/ANAME types instead.

3. Route mail with an MX record

MX records tell sending mail servers where to deliver mail for your domain. The value is always a hostname, never an IP. Your mail provider supplies it — Google Workspace, for example, uses a single record:

Priority orders multiple MX records: lowest number wins, higher numbers are fallbacks. With one record the value barely matters, but the field is required.

4. Publish policy and proofs with TXT records

TXT records hold arbitrary strings, used for domain-verification tokens and email policy. Add Google's recommended SPF record, which lists who may send mail as your domain:

Swap the include: for your provider's SPF domain if you're not on Google. A domain can hold many TXT records, but only one starting with v=spf1.

Verify it works

Query each record type. +noall +answer strips dig's output down to the answer section:

dig +noall +answer example.com A
dig +noall +answer www.example.com CNAME
dig +noall +answer example.com MX
dig +noall +answer example.com TXT

Expected output (name, TTL remaining, class, type, value):

example.com.        300   IN  A      203.0.113.10
www.example.com.    300   IN  CNAME  example.com.
example.com.        3600  IN  MX     1 smtp.google.com.
example.com.        3600  IN  TXT    "v=spf1 include:_spf.google.com ~all"

A TTL below what you configured means you got a cached answer counting down — that's normal. To bypass your local cache and ask a specific public resolver, prepend @:

dig @1.1.1.1 +short example.com A

203.0.113.10

For a second opinion from the browser, use Google Admin Toolbox Dig, and check propagation across dozens of countries at DNSChecker — new records typically appear worldwide within minutes, but resolvers that cached the old state serve it until the old TTL expires.

Troubleshooting

;; connection timed out; no servers could be reached — dig couldn't reach a resolver at all. You're offline, a firewall is blocking port 53, or the @server you specified is wrong. Try dig @1.1.1.1 example.com to isolate it.

status: NXDOMAIN in the header — the name doesn't exist anywhere. Check for a typo, and confirm your registrar actually points at the nameservers where you added records: dig +short example.com NS.

status: NOERROR but ANSWER: 0 — the name exists but has no record of the type you asked for. You added the wrong type, or the record hasn't reached that resolver yet. Ask an authoritative nameserver directly, since it never serves stale data: dig @$(dig +short example.com NS | head -1) example.com A.

Old value keeps coming back — caching. Resolvers hold the previous answer for its full original TTL, and you can't flush caches you don't own. Wait it out, and set TTLs to 300 before future migrations.

Next steps

Run dig +trace example.com to watch delegation walk from the root servers down — the best way to internalize how resolution actually works. Then add AAAA (IPv6) records, finish your email hygiene with DKIM and DMARC TXT records, and look into DNSSEC to sign your zone.
